TOA IP-A1SC15 IP Horn Speaker for Public Address & Voice Evacuation Systems

Name: TOA IP-A1SC15 IP Horn Speaker for Public Address &amp; Voice Evacuation Systems
SKU: FSIN0000362027
Price: 121540.00 INR
Availability: InStock

See all products from toa

₹ 121,540.00 GST included

124dB (PoE+ powered) with IP66 rating for Outdoor Installations. Receive SIP audio, ONVIF and Multicast. Local Broadcast using Internal Audio files. 8W (PoE)/ 15W(PoE+) Built-in Amplifier. 2 Control inputs and 1 Control output. HTTP/HTTPS commands (receive). Audio File storage (20 files, Total 80MB, WAV/MP3). Playback Programs (Repeat, Weekly Timer). PoE/ PoE+ powered.

In stock

Compare

Product Code : FSIN0000362027 Brand: TOA Seller: Approved by : [woo_pro_badges_extended]

quick processing
WARRANTY
For 365 days
always authentic
Only Reputed Brands
EASY PAYMENT
Multiple payment options

Description

TOA IP Horn Speaker, IP-A1SC15 is an IP Paging Horn Speaker to Deliver clear Announcements via Network with 124 dB Output Capability powered by PoE+ Power Source. Its Rugged enclosure is IP66 rated for Outdoor Environments. The IP-A1SC15 Supports Common Network Protocols for easy Integrations with Video Management Systems and other SIP-compatible VoIP systems and Devices. Group paging function is Available with 20 Multicast ports for Zone Paging Requirements. Internal Sound Source file storage allows Storing Pre-recorded messages or Tones which can be played back by 2 Control Inputs or Remote API (HTTP/HTTPS).

Features

124dB (PoE+ powered) with IP66 rating for Outdoor Installations
Receive SIP audio, ONVIF and Multicast
Local Broadcast using Internal Audio files
8W (PoE)/ 15W(PoE+) Built-in Amplifier
2 Control inputs and 1 Control output
HTTP/HTTPS commands (receive)
Audio File storage (20 files, Total 80MB, WAV/MP3)
Playback Programs (Repeat, Weekly Timer)
PoE/ PoE+ powered

Specifications

Brand : TOA
Power Source : PoE plus (IEEE802.3at Class 4)
Power Consumption : 22 W (at PoE+ powered, rated output), 12.95 W (at PoE powered, rated output), 5 W (IEC62368-1)
Amplifier Rated Output : 15 W (at PoE+ powered), 8 W (at PoE powered)
Frequency Response : 280 Hz to 12.5 kHz
Sensitivity : 112 dB (1 W, 1 m) (500 Hz to 2.5 kHz, peak level)
Audio Codec : Opus, PCMU (G.711u), PCMA (G.711a), G.722
Network I/F : 100BASE-TX, MDI/MDI-X, RJ-45
Finish : Horn flare and body: Aluminum, off-white (RAL 9010 equivalent), paint, Reflector horn: ABS resin, off-white (RAL 9010 equivalent), Rear cover: PC resin, off-white (RAL 9010 equivalent), paint, Bracket, screws and bolts: Stainless steel
Dimensions 222 (W) x 211 (H) x 276 (D) mm (8.74 inch x 8.31 inch x 10.87 inch)
Weight : 1.4 kg (3.09 lb)
Included Accessories : Rear cover x 1, Removable terminal plug (3 pins) x 2
