TOA System Management Amplifier, VM-2120

Name: TOA System Management Amplifier, VM-2120
SKU: FSIN0000362331
Price: 68322.00 INR
Availability: InStock

See all products from toa

₹ 68,322.00 GST included

Programmable System Management Amplifier. 120 W or 240 W. 5 Switchable High Impedance Speaker Zones with adjustable Attenuators. 9 Units can be combined to increase the Output Power and Number of Zones. 4 Input Channels come with Volume and Bass/ Treble Control on the front panel. Both BGM inputs with level Pre-adjustment. The routing to the zones of the 3 microphone/ line level inputs and the telephone paging input can be pre-set. Emergency Power input, remote power control, 7 built-in chimes etc.

In stock

Compare

Product Code : FSIN0000362331 Brand: TOA Seller: Approved by : [woo_pro_badges_extended]

quick processing
WARRANTY
For 365 days
always authentic
Only Reputed Brands
EASY PAYMENT
Multiple payment options

Description

TOA System Management Amplifier, VM-2120 is a Multifunctional Amplifier that can be mounted in an EIA-Standard equipment rack (3-unit size). The unit comes with 4 audio inputs including the background music input, and the speaker output section which has an internal attenuator and 5-zone selector. It permits not only general-purpose broadcast, but also Emergency Broadcast based on the EN60849 Standard which gives pre-recorded voice instructions (optional EV-200M is required) in the emergency situation. Broadcast can be made from an optional RM-200M Remote Microphone as well as from the amplifier, and can be remotely controlled from external equipment.

Features

Programmable System Management Amplifier
120 W or 240 W
5 Switchable High Impedance Speaker Zones with adjustable Attenuators
9 Units can be combined to increase the Output Power and Number of Zones
4 Input Channels come with Volume and Bass/ Treble Control on the front panel
Both BGM inputs with level Pre-adjustment
The routing to the zones of the 3 microphone/ line level inputs and the telephone paging input can be pre-set
Emergency Power input, remote power control, 7 built-in chimes etc

Specifications

Brand : TOA
Power Source : AC: 230 V, 50/60 Hz, DC: 24 V/7.5 A, M3.5 screw terminal, Barrier distance: 8 mm (0.31 inch), Applicable cable gauge: AWG22 – AWG14
Power Consumption on AC Mains : 37 W
Rated Output : 120 W
Output Voltage/ Impedance : 100 V/83 ohm, 70 V/42 ohm, 50 V/21 ohm (selectable by the internal wiring change)
Frequency Response : 50 Hz – 16 kHz
Distortion : 1 percent or less
Signal-to-Noise Ratio : 60 dB or more
Tone Control : Bass: 100 Hz plus or minus 10 dB, Treble: 10 kHz plus or minus 10 dB (Inputs 1 – 3 and BGM individually adjustable.)
Finish - Panel: ABS resin, dark gray (PANTONE 447C or its equivalent), paint, Case: Steel plate, dark gray (PANTONE 446C or its equivalent), paint
Dimensions : 419 (W) x 143.3 (H) x 355.7 (D) mm (16.5 inch x 5.64 inch x 14 inch)
Weight : 14.5 kg (31.97 lb)
