TOA Unbalanced Line Input, U-01F

Name: TOA Unbalanced Line Input, U-01F
SKU: FSIN0000362321
Price: 3068.00 INR
Availability: InStock

See all products from toa

₹ 3,068.00 GST included

For Unbalanced, line level Sources such as Tuners, Cassette Decks, CD players, Computer sound cards, Jukeboxes, Mixers and Satellite Receivers. Use for Adjacent Sources (less than 15ft from the host unit). Connectors: Female XLR.

In stock

Compare

Product Code : FSIN0000362321 Brand: TOA Seller: Approved by : [woo_pro_badges_extended]

quick processing
WARRANTY
For 365 days
always authentic
Only Reputed Brands
EASY PAYMENT
Multiple payment options

Description

TOA Unbalanced Line Input, U-01F is a Line Input Module to be used in Conjunction with the 900 series Components and other TOA’s equipment. It has an Unbalanced line input with Female XLR type Connector, and gain control.

Features

For Unbalanced, line level Sources such as Tuners, Cassette Decks, CD players, Computer sound cards, Jukeboxes, Mixers and Satellite Receivers
Use for Adjacent Sources (less than 15ft from the host unit)
Connectors: Female XLR.

Specifications

Brand : TOA
Power Supply : 24 V DC (supplied from the main frame)
Current Consumption : 4 mA
Input Sensitivity : minus 20 dB (rated output: minus 20 dB), adjustable: minus 20 to plus 10 dB
Input Impedance : 220 kohm, unbalanced
Frequency Response : 20 Hz to 20 kHz plus or minus 1.0 dB
Distortion : 0.05 percent or less (1 kHz, output: 0 dB)
Noise Level : minus 106 dB (20 Hz - 20 kHz BPF)
Gain : minus 30 to 0 dB
Connector : Female XLR connector (XLR-3-31 equivalent)
Dimensions : 35 (W) x 78 (H) x 88 (D) mm (1.38 inch x 3.07 inch x 3.46 inch)
Weight : Max. 75 g (0.17 lb)
