Ambetronics Flame Proof Gas detector for all type of gases
₹ 56,286.00 GST included
Versatile Gas Detection. Smart Sensor Modules. Wide Detection Range. LED Display and Status Indicators. Flameproof and Intrinsically Safe. RS-485 Communication. Non-Intrusive Programming. Password Protection. Optional STEL and TWA Set Points. Alarm Relay and Acknowledgement
In stock
Description
Ambetronics Flame Proof Gas detector for all tpe of gases is a Flameproof, PESO Certified Smart Gas Detector designed for swift and reliable detection of Oxygen, Toxic, Combustible, and Volatile Organic Compounds (VOC) gas leaks. Featuring an 8 x 2 Alphanumeric LCD with configurable backlit and 8 LEDs for status indication, it provides a clear digital display of gas concentration. The device offers a standard 4-20mA signal output with a configurable range and three relay outputs with a 5A rating. Optional Isolated RS-485 Communication Port with MODBUS RTU PROTOCOL enhances connectivity. With a hot-swappable gas sensor module, the detector ensures easy maintenance, storing calibration data, alarm data, offset data, and output current data in the sensor module. Non-intrusive programming for the Flameproof Model is facilitated using a Magnetic Wand.
Features
- Versatile Gas Detection. Smart Sensor Modules. Wide Detection Range
- LED Display and Status Indicators
- Flameproof and Intrinsically Safe
- RS-485 Communication
- Non-Intrusive Programming.
- Password Protection
- Optional STEL and TWA Set Points
- Alarm Relay and Acknowledgement
Specifications
- Brand : Ambetronics
- Sensor Technology : Electrochemical, Catalytic, Pellistor, NDIR, PID, Solid State for diverse gas detection
- Detection Method : Diffusion for efficient and reliable gas sensing.
- Response Time : Less than 15 seconds, depending on the type of gas.
- Electrical Requirements : 18 to 36 VDC supply voltage, typically 24VDC, with less than 3.6 Watts power consumption.
- Environmental Resilience : Operating temperature from Minus 15 to Plus 55Deg C, storage from Minus 10 to 60 Deg C, and humidity less than 95Percent non-condensing
- Dimensions : Compact design with or without hooter cum flasher, suitable for various mounting options.
