GST – Digital Flame Proof UV Flame Detector – DI-9104Exd

Name: GST - Digital Flame Proof UV Flame Detector - DI-9104Exd
SKU: FSIN00003329
Price: 177177.00 INR
Availability: InStock

See all products from gst

₹ 177,177.00 GST included

The GST Digital Flame Proof UV Flame Detector DI-9104Exd is a highly reliable flame detection device designed for hazardous and explosive environments. Built with advanced UV sensing technology, it provides rapid detection of ultraviolet radiation emitted by flames, ensuring fast response to fire hazards. With a flameproof enclosure, the DI-9104Exd is suitable for use in industries such as oil & gas, chemical plants, refineries, and other high-risk facilities.

Compare

Product Code : FSIN00003329 Brand: GST Seller: Approved by : [woo_pro_badges_extended]

quick processing
WARRANTY
For 365 days
always authentic
Only Reputed Brands
EASY PAYMENT
Multiple payment options

Description

Features

Built-in MCU processes signals and controls communication digitally
Intelligent algorithm ensures quick response to reduced false alarms.
3 classifications available
High sensitivity, reliable performance, and dust-proof, damp-proof and corrosion-proof abilities

Specifications

Operating Voltage Addressable Mode: Loop voltage: 24VDC come from FACP Z1,Z2 terminals
Operating Current Addressable Mode: Standby current ≤ 2mA Alarm current ≤ 3mA
Indicator In addressable mode and non-addressable mode, indicator is red. It flashes when polling, and illuminates steadily in alarm.
Address Range 1～242
Spectrum Response Range 185nm～260nm
Weight 1.5kg
Installation Hole Spacing 110mm×72mm
