GST Isolator Base, DC-9504E (MOQ-2Pcs)
₹ 1,357.00 GST included
Polarity-sensitive External Connections. Input and Output can be used Inversely without Direction. Delayed Power-up to Output end Devices. Avoids strong Transient Current the Load is Heavy. Applicable to all kinds of Loop Fire Alarm Systems. Suitable for A and Class B.
In stock
Description
GST Isolator Base, DC-9504E is In Loop type Fire Alarm System, it often occurs that Partial Short Circuit of Loop affects the whole system. This Loop Isolator can Isolate the Shorted Circuit from thec complete loop to ensure Normal Operation of other parts and locate the isolated part. The Isolator is Applicable to all kinds of Loop Fire Alarm Systems, suitable for Class A and Class B. As a Base type, the Isolator can be used to replace a common Base, to save Installation and Cabling.
Features
- Polarity-sensitive External Connections
- Input and Output can be used Inversely without Direction
- Delayed Power-up to Output end Devices
- Avoids strong Transient Current the Load is Heavy
- Applicable to all kinds of Loop Fire Alarm Systems
- Suitable for A and Class B
Specifications
- Brand : GST
- Maximum Operation voltage : 28VDC
- Operating Voltage : 24 V
- Minimum Operating Voltage : 16 V
- Maximum Open Voltage : 11V
- Minimum Open Voltage : 8V
- Action LED : Yellow. It flashes in standby state. And lights in aciton.
- Capacity : Maximum 70 Devices
- Material of Enclosure : ABS
