Ravel RE-2558 Conventional Fire Alarm Panel System 8 Zones

Name: Ravel RE-2558 Conventional Fire Alarm Panel System 8 Zones
SKU: FSIN00001370
Price: 14455.00 INR
Availability: InStock

See all products from ravel

₹ 14,455.00 GST included

Switched Mode Power Supply. Modular Construction Auto Resettable Fuse Surge Protection for all Input and outputs. Programmable AC loss delay/Trouble Remainder/Alarm Verification Battery polarity reversible protection Surface Mount Technology Over All current consumption is low. Fully complies with UL -864 and NFPA-72. Rugged CRCA sheet with powder coated finish Operates on 110 220v 50 /60 Hz, AC Mains power supply. 16×2 Dot Matrix LCD Display. 4/8 Class B Style B or Style C initiating device circuit (IDC). All zones accept smoke detectors and any normally open contact device. Any Zone can be configured as Alarm or supervisory Zone. 2ClassBNotificationApplianceCircuits(NAC). NAC shall be programmed as silenceable or Non Silenceable. Supervisory Zone shall be Latching or Resettable. Standby (battery) backup 24v DC power supply with built in charger Error free Fire / Fault status in unambiguous colored LED indication. System ON indication. Main, Standby status audible and visual indication. Battery Low visual warning with audible tone. FormC relays for fire, fault and supervisory. Resettable / Steady 24V D.C. Output. RS 485 Communication facility (Optional). Lamp Test facility. All field wiring circuits are Power limited except 110 220v AC and Battery. All field wiring circuits are supervised. Walk Test facility. Zone Isolation facility with loop voltage cut off. Earth fault annunciation facility at 0 ohms. AC Low voltage cutoff. Programmable AC loss delay / Alarm verification / Trouble reminder.

Compare

Product Code : FSIN00001370 Brand: Ravel Seller: Approved by : [woo_pro_badges_extended]

quick processing
WARRANTY
For 365 days
always authentic
Only Reputed Brands
EASY PAYMENT
Multiple payment options

Description

The microprocessor based UL listed 8 Zone conventional fire alarm control panel, the system has 16 X 2 LCDcharacter, 8 zones detection circuit,3 common potential free contacts &2 common NAC sounder output, inbuilt Rs-485 for repeater connectivity, wall/ceiling mounted, Switch mode power supply- SMPS & Battery polarity & Deep discharge protection. RE-2558 fire alarm control panel is designed with unique protocol to be used for small & medium establishments, Schools, hospitals, hotels, banks, residential / commercial building, and small scale industries. The system is user friendly with includes all standard to ensure ease for use and high reliability. Switched Mode Power Supply. Modular Construction Auto Resettable Fuse Surge Protection for all Input and outputs. Programmable AC loss delay/Trouble Remainder/Alarm Verification Battery polarity reversible protection Surface Mount Technology Over All current consumption is low. Fully complies with UL -864 and NFPA-72. Rugged CRCA sheet with powder coated finish Operates on 110 220v 50 /60 Hz, AC Mains power supply. 16×2 Dot Matrix LCD Display. 4/8 Class B Style B or Style C initiating device circuit (IDC). All zones accept smoke detectors and any normally open contact device. Any Zone can be configured as Alarm or supervisory Zone. 2ClassBNotificationApplianceCircuits(NAC). NAC shall be programmed as silenceable or Non Silenceable. Supervisory Zone shall be Latching or Resettable. Standby (battery) backup 24v DC power supply with built in charger Error free Fire / Fault status in unambiguous colored LED indication. System ON indication. Main, Standby status audible and visual indication. Battery Low visual warning with audible tone. FormC relays for fire, fault and supervisory. Resettable / Steady 24V D.C. Output. RS 485 Communication facility (Optional). Lamp Test facility. All field wiring circuits are Power limited except 110 220v AC and Battery. All field wiring circuits are supervised. Walk Test facility. Zone Isolation facility with loop voltage cut off. Earth fault annunciation facility at 0 ohms. AC Low voltage cutoff. Programmable AC loss delay / Alarm verification / Trouble reminder.

Features

Switched Mode Power Supply.
Modular Construction
Auto Resettable Fuse
Surge Protection for all Input and outputs.
Programmable AC loss delay/Trouble Remainder/Alarm Verification
Battery polarity reversible protection
Surface Mount Technology
Over All current consumption is low.
Fully complies with UL -864 and NFPA-72.
4/8 Class B Style B or Style C initiating device circuit (IDC). All zones accept smoke detectors and any normally open contact device.Any Zone can be configured as Alarm or supervisory Zone.
Operates on 110 220v 50 /60 Hz, AC Mains power supply.
16×2 Dot Matrix LCD Display.
4/8 Class B Style B or Style C initiating device circuit (IDC). All zones accept smoke detectors and any normally open contact device. Any Zone can be configured as Alarm or supervisory Zone.
2ClassBNotificationApplianceCircuits(NAC).
NAC shall be programmed as silenceable or Non Silenceable.

Specifications

Electrical Specification : Primary Power : 120 220VAC ± 10%, 50 Hz, 2.5Amps.
Standby Power : 24V D.C (2 Nos of 12v, 12Ah Sealed Lead acid battery). Quiescent current: 120mA
Operating Condition : Operating Temperature 0 49° C / 32 120° F. Relative Humidity 93 ± 2% RH (non-condensing) at 32 ± 2° C / 90 ± 3° F.
Charging Circuit : Charging Voltage 28.2V, ±0.5V Charging Current 800mA (Max.).
D.C. Output : Supervised 24VDC regulated, 300mA Max.
Common Relays : Type : Form C No of Relays : 3 Relay Contact Rating : 2Amps @ 30 VDC, 0.5Amps @ 125VAC. Power Factor : 1.0
Initiating Device Circuits : All zones are Class B Style B/C operation (Programmable). Normal Operating Voltage: 14 21 VDC. Alarm Current: 15 30mA. Short Circuit Current: 45mA Maximum. Loop resistance: 100 ohms Maximum. End-Of-Line Resistor: 3K9, 1/2watt Standby Current: 7mA (2mA for Detectors)
Notification Appliance Circuits : Class B Style Y wiring Operating Nominal Voltage: 24VDC Special Application Current for all NACs: 1.2Amps (0.6A per circuit) Line Drop: 1.8V End-Of-Line Resistor: 3K9, 1/2watt
Mechanical Specification : Dimensions : (440W X 340H X 120D) Color : Red / White Construction : 18 Gauge (1.22mm) CRCA sheet with powder-coated Finish IP Rating : IP50 Cable Entry : 11xø19mm Knockout in top of the cabinet 10xø22.25mm Knockout in top of the cabinet
