TOA Assignable Volume Controller, ZM-9012

Name: TOA Assignable Volume Controller, ZM-9012
SKU: FSIN0000362409
Price: 21476.00 INR
Availability: InStock

See all products from toa

₹ 21,476.00 GST included

Rotary Encoder can be Assigned to Control any Input or Output Volume. Designed for Exclusive use with the 9000M2 Series or M-864D. Wall Mounted Remote Control Panel. Volume Control Knob.

In stock

Compare

Product Code : FSIN0000362409 Brand: TOA Seller: Approved by : [woo_pro_badges_extended]

quick processing
WARRANTY
For 365 days
always authentic
Only Reputed Brands
EASY PAYMENT
Multiple payment options

Description

TOA Assignable Volume Controller, ZM-9012 is Designed for exclusive use with the 9000M2 Series or M-864D, the ZM-9012 is a Wall Mounted Remote Control Panel having a Volume Control Knob. It is used in conjunction with the RC-001T Remote control module or M-864D. It can be mounted in a standard 1-gang electrical box in the wall.

Features

Rotary Encoder can be Assigned to Control any Input or Output Volume
Designed for Exclusive use with the 9000M2 Series or M-864D
Wall Mounted Remote Control Panel
Volume Control Knob

Specifications

Brand : TOA
Power Source : 24 V DC (supplied from RC-001T or M-864D)
Current Consumption : 50 mA or less
Control : 1 Volume Control
Indicator : Level indicators (green LEDs)
Cable Requirements : Shielded CPEV cable (paired data line and paired power line) or Category 5 twisted pair cable for LAN (CAT5-STP)
Terminal : Removable Terminal block (10 pins)
Operating Temperature : 0 deg.C to plus 40 deg.C (32 deg. F to 104 deg.F)
Operating Humidity : 35 percent to 80 percent RH (no condensation)
Finish : Surface-treated steel plate, white, paint
Dimensions : 72 (W) x 127 (H) x 49.5 (D) mm (2.83 x 5 inch x 1.95 inch)
Weight : 208 g (0.46 lb)
Included Accessories : Box mounting screw (No.6-32UNC x 30) …2, Box mounting screw (M4 x 30) …2, Panel mounting screw …2,Removable terminal plug (10 pins) …1
