Simplex – Model 4090-9001 Supervised Individual Addressable Module (IAM)
See all products from simplex₹ 3,363.00 GST included
The Simplex 4090-9001 is a compact, addressable monitor module designed to integrate conventional fire alarm devices into the Simplex addressable fire alarm control panel (FACP) network. It allows you to monitor dry contact devices like waterflow switches, manual call points, tamper switches, and other contact-type initiating devices.
Description
The Simplex 4090-9001 is a compact, addressable monitor module designed to integrate conventional fire alarm devices into the Simplex addressable fire alarm control panel (FACP) network. It allows you to monitor dry contact devices like waterflow switches, manual call points, tamper switches, and other contact-type initiating devices.
With its compact size, low power consumption, and high reliability, the 4090-9001 monitor module is ideal for both retrofit and new installations, providing intelligent supervision and status reporting directly to the control panel.
Features
- Addressable Device: Supports individual addressing via DIP switch for precise identification.
- Compact Design: Small, lightweight module fits inside single-gang electrical boxes or device enclosures.
- Intelligent Monitoring: Reports device status (normal, open, short, or active) back to the fire alarm panel.
- Built-in Short Circuit Isolation: Prevents entire loop failure during a short circuit (when installed with isolator).
- Low Power Draw: Helps maximize loop capacity.
- Universal Compatibility: Works with a wide range of dry contact devices like sprinkler waterflow and tamper switches.
- Mounting Flexibility: Mounts directly inside electrical backboxes or within equipment enclosures
Specifications
- Model 4090-9001
- Type Addressable Monitor Module
- Mounting Type Surface or electrical box (single-gang)
- Input Monitoring Dry contacts (NO or NC)
- Operating Voltage Supplied from Signaling Line Circuit (SLC)
- Current Draw Low (varies by control panel type)
- Temperature Range 32°F to 120°F (0°C to 49°C)
