Edward SIGA-CC1 Addressable Control Interface Module for Hooter/Strobe or Hooter
₹ 3,776.00 GST included
Edward SIGA-CC1 Addressable Control Interface Module for Hooter/Strobe or Hooter Upon command from the loop controller, the module connects supervised Class B signal or telephone circuits to the respective riser input. The riser input can be 24 VDC (to operate polarized audible and visible signal notification appliances), 25 or 70 VRMS (to operate audio evacuation speakers), or firefighter telephones.
In stock
Description
Edward SIGA-CC1 Addressable Control Interface Module for Hooter/Strobe or Hooter Upon command from the loop controller, the module connects supervised Class B signal or telephone circuits to the respective riser input. The riser input can be 24 VDC (to operate polarized audible and visible signal notification appliances), 25 or 70 VRMS (to operate audio evacuation speakers), or firefighter telephones. The module does not provide signal synchronization. To meet UL 864 requirements for horn and strobe signal synchronization, you must install a Genesis Signal Master module. The SIGA-CC1 module requires one address on the signaling line circuit (SLC). Addresses are assigned electronically. There are no address switches.
Features
- Optional covers are available to allow LED to be viewed after installation (requires mounting bracket, ordered separately)
- Supervised Class B monitoring of normally open, dry contacts
- Visible LED flashes to indicate communications
- Mounts in standard single gang electrical box
- Enclosed design minimizes dust infiltration
- Screw terminals for wiring connections
Specifications
- Brand: Edward
- Condition New
- Usage/Application Fire Detection
- Input Output Control Method 24 VDC
- Basic Error Limit Voltage Ranges 24 VDC
- Current Consumption From Backplane Bus 5 AMP
